Beam Splitter
C-mount
Inbuilt Camera attachment
HD CMOS Camera (Resolution 1080p)
NEW APPROACH FOR VISUALIZATION
The apochromatic optics of our surgical microscope offers high-contrast and colorfast visualization solutions in both changer system and in the motorized zoom system. The zoom system in the range of 1:6 also allows a flexible adjustment of working distance and magnification to the current treatment situation.
You can quickly and easily switch between the detailed field of view (maximum magnification) and the overview field (the largest possible field of view) without any restriction of stereoscopic vision.
The ophthalmic surgical microscopes are equipped with either high power LED or 15 V / 150 watt coaxial fiber optic illumination, specially adapted for ophthalmological applications, with a built-in UV filter. In combination with the optics, it allows a bright red reflex, making every layer and every detail of the retina visible without risking to hurt the patient‘s eye.
The compact design allows a short working distance of the surgeon to the surgical field and is extremely user-friendly. All microscope movements are performed with minimal effort.
| Optics | Apochromatic |
| Binocular View | 45º Inclined Binocular Tube |
| Interpupillary distance | 50mm to 75mm |
| Eye Piece | 10X widefield & high eye Point (Diopter adjustment +6 to -6) (Optional: 12.5X Eye Piece |
| Magnification | 0.4X, 0.6X, 1.0X, 1.6X, 2.5X |
| Objective Focal Length | F = 200 mm |
| Fine Focus | 40mm by Foot Switch |
| Illumination | Shadow free Bright White Spot by 6º Oblique Illumination with +2º to 4º continuous variable illumination for bright red reflex |
| Lamp Life | 50000 hrs (for LED Illumination) |
| Light Source | Integrated High power LED source |
| Power Supply | AC 230V / 50Hz |
| Weight | ± 80Kg |
| Optional | 0° - 210° Tiltable binocular Tube |
| Optics | Apochromatic |
| Binocular View | 45º Inclined Binocular Tube |
| Interpupillary distance | 50mm to 75mm |
| Eye Piece | 10X widefield & high eye Point (Diopter adjustment +6 to -6) (Optional: 12.5X Eye Piece |
| Magnification | 0.4X, 0.6X, 1.0X, 1.6X, 2.5X |
| Objective Focal Length | F = 200 mm |
| Motorized Fine Focus | 40mm by Foot Switch |
| Illumination | Shadow free Bright White Spot by 6º Oblique Illumination with +2º to 4º continuous variable illumination for bright red reflex |
| Lamp Life | 50000 hrs (for LED Illumination) |
| Light Source | High power LED through fiber optic cable |
| Filters | Heat absorbing and UV filters Halogen Color Filter |
| Power Supply | AC 230V / 50Hz |
| Weight | ± 160Kg |
| Optinal | |
| Optional | 0° - 210° Tiltable binocular Tube 90° Tiltable binocular Tube |
| X-Y coupling movement | 50mm x 50mm |
| Objective Focal Length | i-Focus 200mm Motorized control |
| Magnification | Zoom 1:6 ratio Magnification (0.4X to 2.4X) |
